Description

• Maximum Output Power1 x 4000W (1Ω), 1 x 3000W (2Ω), 1 x 1500W (4Ω)

• Continuous power output (RMS)

  •1 x 2000W (50Hz/1Ω ≤ 1%THD)

  •1 x 1500W (50Hz/2Ω ≤ 1%THD)

  •1 x 750W (20Hz – 240Hz/4Ω ≤ 1%THD)

• Load impedance capability 1 – 8Ω

• Frequency response 10 – 240Hz

• Distortion < 0.3%

• S/N ratio > 85dB

• Bass Boost 40 – 120Hz

  0, 6, 9, 12 dB via remote control

• LPF 40 – 240Hz (-24dB/Oct)

• Subsonic Filter (HPF) 20Hz (-24dB/Oct)

• MOSFET output section Ja

• Sync Control Ja

• RCA terminals Yes (input/output)

• Speaker Terminals Block-type

• High Voltage Input 200mV – 6.5V

• Input level control 400 mV – 6.5 V

• Highperformancebalancedisolatorcircuit Ja

• Max. current consumption (A/4Ω) 67A

• Chassis size (W x H x D) 586 x 65 x 282mm
